Intel Xeon E5-2630V4 2.2 GHz BOX

General information

• Type CPU / Microprocessor Market segment Server
• Family Intel Xeon E5-2600 v4
• Model number ? E5-2630 v4
• Frequency ? 2200 MHz
• Turbo frequency 3100 MHz
• Bus speed ? 8 GT/s QPI (4000 MHz)
• Clock multiplier ? 22
• Package 2011-land Flip-Chip Land Grid Array
• Socket Socket 2011-3 / R3 / LGA2011-3

Architecture / Microarchitecture

• Microarchitecture Broadwell
• Platform Grantley-EP
• Processor core ? Broadwell-EP
• Core stepping ? R0 (QKET, QKRH, SR2R7)
• CPUID 406F1 (QKET, QKRH)
• Manufacturing process 0.014 micron
• Data width 64 bit
• The number of CPU cores 10
• The number of threads 20
• Floating Point Unit Integrated
• Level 1 cache size
  • 10 x 32 KB 8-way set associative instruction caches
  • 10 x 32 KB 8-way set associative data caches
• Level 2 cache size  10 x 256 KB 8-way set associative caches
• Level 3 cache size 25 MB 20-way set associative shared cache
• Physical memory 1536 GB
• Multiprocessing Up to 2 processors
• Features
  • MMX instructions
  • SSE / Streaming SIMD Extensions
  • SSE2 / Streaming SIMD Extensions 2
  • SSE3 / Streaming SIMD Extensions 3
  • SSSE3 / Supplemental Streaming SIMD Extensions 3
  • SSE4 / SSE4.1 + SSE4.2 / Streaming SIMD Extensions 4
  • AES / Advanced Encryption Standard instructions
  • AVX / Advanced Vector Extensions
  • AVX2 / Advanced Vector Extensions 2.0
  • BMI / BMI1 + BMI2 / Bit Manipulation instructions
  • F16C / 16-bit Floating-Point conversion instructions
  • FMA3 / 3-operand Fused Multiply-Add instructions
  • EM64T / Extended Memory 64 technology / Intel 64
  • NX / XD / Execute disable bit
  • HT / Hyper-Threading technology
  • VT-x / Virtualization technology
  • VT-d / Virtualization for directed I/O
  • TBT 2.0 / Turbo Boost technology 2.0
  • TXT / Trusted Execution technology
• Low power features Enhanced SpeedStep technology
• Integrated peripherals / components
  • Integrated graphics None
  • Memory controller The number of controllers: 1
  • Memory channels: 4
  • Supported memory: DDR4-1600, DDR4-1866, DDR4-2133
  • Maximum memory bandwidth (GB/s): 68.3
  • ECC supported: Yes
  • Other peripherals
  • Direct Media Interface 2.0
  • Quick Path Interconnect (2 links)
  • PCI Express 3.0 interface (40 lanes)
• Electrical / Thermal parameters
  • Maximum operating temperature  74°C
  • Minimum power dissipation
    • 35 Watt (C1E state)
    • 12 Watt (C6 state)
  • Thermal Design Power  85 Watt
